The AP-YV3302H electrostatic sensor is a detecting instrument developed and produced by Anping Company for measuring static voltage on the surface of objects with static electricity. It adopts non-contact measurement technology to minimize the impact of the detecting instrument on the electrostatic field of the object surface, ensuring high measurement accuracy.
Designed for industrial and laboratory use, the AP-YV3302H offers comfortable feel and beautiful appearance, making it suitable for prolonged operation. The sensor supports selectable detection distance via dial switch, allowing flexible adaptation to different measurement environments and object sizes.
With a wide detection potential range and high detection precision, the device delivers reliable static voltage data. An adjustable alarm threshold is available, and a red light alarm indicates exceeding threshold, providing immediate visual warning when static levels exceed safe limits.
The sensor features a high-definition and all-dimensional LCD data display terminal, enabling clear and intuitive reading of measurement results. For system integration and data analysis, monitoring data can be transmitted to PC in real time, supporting continuous monitoring and documentation.
The AP-YV3302H is conformable for operation and convenient for use, making it suitable for quality control, safety monitoring, and electrostatic management across multiple industries.
TECHNICAL FEATURES
Non-contact measurement technology to minimize impact on electrostatic field
With comfortable feel and beautiful appearance
Detection distance can be selected via dial switch
Wide detection potential range and high detection precision
Alarm threshold can be set with red light alarm indicating exceeding threshold
High-definition and all-dimensional LCD data display terminal
Monitoring data can be transmitted to PC in real time
Conformable for operation and convenient for use
KEY ADVANTAGES
Accurate static voltage measurement using non-contact detection technology
Flexible application with selectable detection distance
Real-time visual warning through adjustable alarm and red light indication
Clear and comprehensive data visualization via HD LCD display
Supports real-time PC data transmission for monitoring and analysis
Ergonomic design for comfortable and convenient operation
TYPICAL APPLICATIONS
Electronics industry
Photoelectric industry
Plastics processing industry
Static control monitoring systems
Electrostatic safety inspection and quality control
